Product Overview

An integrated device that combines indoor/outdoor access points and CPE. The CPE operates at 6GHz, while the AP operates at 2.4/5GHz. It is a perfect client device!

Features:

2x2 6GHz MIMO client

2.4/5GHz Wi-Fi Access Point

WIS OS

Technical indicators

Model	E620C-WiFi
Hardware
CPU	IPQ5312 Qualcomm Quad A53 @ 1.1GHz
CPE Operating Frequency	5.9-7.125GHz
CPE Wireless Standards	WIFI 7/802.11be
CPE Channel Width	20\|40\|80\|160\|320 MHz
CPE Wireless Max data rate	2.3 Gbps
CPE Proprietary Physical Layer	2x2 MIMO
CPE Antenna	20dBi /6GHz
CPE Antenna Beam width	16deg.
AP Wireless Standards	WIFI 7/802.11be
AP Operating Frequency	2.4/5GHz
AP max client	256
AP Antenna	6dBi/2.4GHz and 9dBi/5GHz
AP Antenna Beam width	360deg
AP antenna length	30cm
Networking interface	1*2.5Gigabit Ethernet
LEDs	1Power, 1SYS, 3*Wi-Fi
Power Supply	PoE 22-56V, or DC 12V
Power Consumption	<16W
Surge suppression	8KV
Weatherproof Enclosure	IP67
Size	22324569mm
Weight	1.8kg
PTP Link Distances	10km+
Temperature	-40°C to65°C
Working mode	AP WDS、Client WDS
Network Mode	Bridge/Router
Wireless Security	WPA-PSK，WPA2-PSK,WPA/WPA2-PSK（AES/TKIP）
Network Management	HTTP/HTTPS, SNMPv1/2, SNMPv3, TR069,SSH,
VLAN	802.1Q
DHCP	DHCP Server、DHCP Client

LibreNMS is an open-source network monitoring tool that can monitor a wide range of network devices and also different operating systems such as Linux, Windows as well and pretty much anything that supports SNMP polling.

The top features of LibreNMS monitoring tool:

Automatic Discovery – It will automatically discover your entire network using CDP, FDP, LLDP, OSPF, BGP, SNMP, and ARP.
Customizable Alerting – Supports a customizable alerting system to send notifications through email, IRC, slack, and more.
Customizable Dashboards – It has a mobile-friendly Web UI, with customizable dashboards.
Integration Support – Supports integration with NfSen, collected, SmokePing, RANCID, and Oxidized.
Multiple Authentication Methods – Supports multiple authentication methods such as MySQL, HTTP, LDAP, Radius, and Active Directory.
Billing system – Easily generate bandwidth bills for ports on your network based on usage or transfer.
API Access – Supports an API for managing, graphing, and retrieving data from your system.
Automatic Updates – With LibreNMS you get to stay up to date automatically with new features and bug fixes.
